Dental Electric Suction Machine Vacuum System/air Compressor

Air Compressor

Silent Oil-Free Air Compressor for Dental Use

Product Overview

This oil-free air compressor is designed for dental applications, delivering clean, quiet, and reliable performance. Its advanced features include anti-rust and anti-microbial interior tank coating, ultra-low noise operation, and durable continuous-run capability.

Key Features

Clean Air Assurance:

Oil-free operation with anti-rust and anti-microbial interior tank coating.

Low Noise Design:

Optional silent cabinet reduces noise to just 50dB+(A).

Long Service Life:

Engineered for continuous operation with stable airflow output.

Components List

1.Host Unit

2.Air Tank

3.Emergency Stop Switch (Red Mushroom)

4.Motor Start Switch Equipment Control Box

5.Solenoid Valve

6.Pressure Gauge

7.Safety Valve

8.Compressed Air Output Valve

9.Wastewater & Exhaust Discharge Valve

Operation & Maintenance Guidelines

  The air compressor automatically stops filling when the air pressure in the tank reaches 0.8 MPa, During product use, when the pressure drops to 0.5MPa, the machine will automatically restart and continue operating until the pressure returns to 0.8 MPa. This cycle repeats automatically.

�� Emergency Stop Button

Press the red button to immediately stop the machine in emergencies.

Pull the button upward to reset after resolving the issue.

��️ Air Filter Maintenance

Clean the filter regularly to prevent dust entry and maintain suction efficiency.

Rinse the sound-damping sponge every 30-60 days.

�� Tank Drainage

Drain accumulated water every 3-5 days to maintain tank integrity.

⏱️ Inflation Time Test

Recommended frequency: Monthly

Procedure:

1.Turn off power.

2.Open drain and air outlet valves.

3.Close both valves.

4.Restart the machine and record the time to reach shutoff pressure.

Note:

Normal inflation time: 3–4 minutes.

If exceeding 5 minutes, contact after-sales service.

24L

Model: GA01 24L, 600W

Specification Value

Voltage     120V

Motor Power 600W

Rated Pressure  8 bar

Max. Air Flow  118 L/min

Tank Capacity  24 L

Noise Level  58 dB

Gross Weight 28 kg

Packing Size 440×440×600 mm

Model: GA02 40L, 800W

Specification Value

Voltage     120V

Motor Power 800W

Rated Pressure  8 bar

Max. Air Flow  155 L/min

Tank Capacity  40 L

Noise Level  58 dB

Gross Weight 32 kg

Packing Size 440×440×685 mm

Suction Machine Vacuum System

Models

GS-01

 GS-02

Volt./Hz

110-120V/60HZ

110-120V/60HZ

Power

0.75 KW

1.10 KW

 Max Vacuum

≥－12 KPa

≥－13 KPa

 Pump Flow

≥300L/min

≥600L/min

Noise

60 ±2 dB(A)

60 ±2 dB(A)

Fuse (A)

10

15

Ambient temperature:

5~45 ℃

5~45 ℃

Package Size

67*49*39 cm

69*54*43 cm

 G.W.(Kg)

 35Kg

41Kg

For dental chair

Simultaneous  use100%: 1

Simultaneous  use 60%: 2

Simultaneous  use100%: 2

Simultaneous  use 70%: 3

Air/Water Intake

Translucent steel wire-reinforced hose  Ф40mm l.D. x 1.5m length

Air Outlet

Aluminum foil flex duct  Ф50mm l.D. x lm length

Drainage Outlet

Translucent steel wire-reinforced hoseФ25mm l.D. x 1.5m length

Operating principle:

Connect the suction unit with dental treatment unit, take up saliva ejector from clip-on instrument holder of dental treatment unit, and the suction unit will start automatically to suck foreign objects attached with germina.

Real-time Monitoring

Direct Extraction and Discharge

Delayed Start-Stop

Stable Operation

Convenient Installation

Central Separation

High-Efficiency Suction

Lower Noise

Product Classification

1 Classification of air flow: High volume suction system.

2 Classification of suction method: semi-dry system.

3 Classification of dental equipments management: Oral equipments

and instruments (code 6855), Type I management.

4 Classification of electric shock protection: Type I equipment.

5 Classification of electric shock guarding: Type B equipment.

6 Classification of waterproof: Normal equipment (IP20).

7 Classification of working frequency: intermittent duty.

Working principle overview

Operating principle: Connect the suction unit with dental treatment unit,

take up saliva ejector from clip-on instrument holder of dental treatment

unit, and the suction unit will start automatically to suck foreign objects

attached with germina (such as oral secretion and dirty blood) into filter, the

filter will separate solid particles(such as teeth fragments, silver amalgam

particles) from dirty blood and oral secretion(please clean solid particles

inside the filter regularly).The filtered dirty blood and oral secretion will be

sucked into drain bottle, the air and water separator will separate the air

from dirty blood and oral secretion to ensure the air offered for ring blower

is clean and prevent the impellers from corrosive damage.
